HRE-206 Electrical assembly trainer

Overview

This equipment consists of a multifunctional mounting plate (mesh plate) device made of steel plate and a power supply unit. Various components, devices and parts selected for practical training can be conveniently mounted on the mesh plate, which is convenient and flexible.

According to the needs of teaching and practical training, choose different components, devices and parts, can be carried out in different course modules, different projects of practical training, this equipment is widely applicable, can complete the teaching content and practical training projects. Components, devices and parts used, removed from the equipment, centralised storage, less damage and loss. A training place, can complete several professional teaching and practical training, economical and applicable.

The equipment is equipped with leakage protection, overload and circuit protection to ensure personal safety and equipment safety.

Flexible, reliable, safe and economical is the characteristics of this equipment.

Practical training projects

1. Lighting circuit installation and connection training;

2. Practical training on connection of fluorescent lamps;

3. Application of single-phase energy meter;

4. training of motor pointing and continuous rotation circuit connection;

5. practical training on the connection of motor forward and reverse rotation circuits with push-button interlock;

6. practical training on the connection of motor forward and reverse rotation circuits with contactor interlock;

7. training of motor forward and reverse circuits with double interlocking of contactors and push buttons;

8. installation of motor control circuits for two-place control;

9. practical training on connection of motor stator winding series resistance starting control circuit;

10. training on connection of Y-△ start control circuit switched by push button;

11. time relay switching Y-△ start control circuit connection training;

12. Motor half-wave rectifier energy braking control circuit connection training;

13. Motor full-wave rectifier energy braking control circuit connection training;

14 motor reverse braking control circuit connection training;

15. Motor round trip control circuit connection training;

16. Motor sequential start control circuit connection training;

17. Motor timing operation control circuit connection training;

18. Push-button switching of two-speed motor control circuit connection training;

Time relay switching of two-speed motor control circuit connection training
