Technical specifications 1. AC power supply: 380 VAC ±10% 50 Hz. 2. Temperature: -10 to 40 °C; ambient humidity: ≤ 90% (25 °C). 3. Size of wind power unit: 1100*1000*1000MM 4. Size of photovoltaic unit: 1200*769*1483MM 5. Size of training table: 1750*750*1750 MM 6. Power consumption of whole machine: ≤ 6.0 kW 7. safety protection measures: battery over-charge and over-discharge protection, battery open circuit protection, load over-voltage protection, output short circuit protection, safe
General description
With the approaching energy crisis, new energy sources have become one of the world's major energy sources in the future. Among them, solar power has gradually entered our ordinary life, while wind power generation can occasionally be seen or heard, wind and solar complementary power generation system is the use of wind and solar energy resources complementarity, with a high cost performance of a new power generation system, has a very good application prospects.
In response to this phenomenon, our company has developed the wind and solar power generation training system HRN-1201. The equipment is installed and produced using all industry standard electrical equipment, and all power generation devices use real power generation equipment and present the basic principles of wind and solar power generation on the training table. It demonstrates the principles and components of solar power generation and guides students through each of the solar and wind power generation processes. It also demonstrates the effects of power generation applications and is suitable for use in major institutions.
Practical training projects that can be carried out with this equipment
1.Wind speed regulation training in the wind tunnel 2.
2. Inverter adjustment training
3.Wind speed detection training
4. Wind direction detection training.
5. Practical training on the relationship between actual wind speed and generator speed 6.
6. Wind turbine speed training.
7. Practical training on the relationship between generator speed and output voltage.
8. Practical training on the relationship between generator speed and output current 9.
9. Practical training on the energy conversion of photovoltaic solar panels.
10. Hands-on training on the environmental impact of photovoltaic conversion 11.
11.Hands-on training on DC load characteristics of energy storage devices 12.
12.Practical training on battery overcharge protection by solar controller 13.
13.Practical training on battery over-discharge protection by solar controller 14.
14.Practical training on the protection of the solar panels against inversion
15.Knowledge of the principle of operation of the off-grid inverter.
16. Practical training on the characteristics of off-grid inverters connected to AC loads 17.
17.Practical training on charging and testing the controller at the same time 18.
18.Practical training on DC charging
19. Practical training on AC load
20. Practical training on sensors
