HR-PF01 Didactic bench for studying UHT treatment

1,Material: contact part 316L stainless steel

2,Research object: milk, fruit juice, sticky food;

3,Product flow: 20-100L/H;

4,Tube sterilisation temperature: 85-95°C; plate sterilisation temperature: 95-135°C;

5,Feed temperature: room temperature; discharge temperature: 30-40°C

6,Internal pressure: 5bar

7,Cavitation time about 120s

8,Detachable static stirrer, allowing viscous products to pass through the tube exchanger

9,Command and control panel: adjustment and display

10,Flow rate of heating liquid and cooling liquid can be displayed by rotor flow meter

11,Device for data acquisition and transfer to PC computer

12,Data processing and development software

13,Provision of hot water, steam, cold water and compressed air connections
