HRA-104S Multi-function material sorting training equipment

1、AC power supply: three-phase five-wire AC 380 V±10% 50Hz;
2、Temperature:-10～50℃；Ambient humidity:≤90% no water bead condensation;
3、Dimensions：L×W×H=1200mm×800mm×1500mm;
4、Power consumption of the whole machine: ≤1.5 kVA;

Product Description:

Functional characteristics

This equipment adopts aluminium alloy rail type practical training table, module using standard structure and drawer type module placing frame, interchangeability; according to the principle of productive function and integration of learning function to determine the module content, so that the teaching can be convenient to select the required module.

The I/O terminals of PLC module, the wiring terminals of frequency converter, the connection terminals of each commonly used module and PLC are connected with safety sockets, and the wires with safety plugs are used to connect the circuits; the circuits of command switches, photoelectric switches, sensors and indicating components are connected through the terminal rows. The combination of plug-in wire connection circuit and terminal row connection circuit not only ensures the training, formation and consolidation of students' basic skills, but also ensures the fast, safe and reliable circuit connection.

Feeding device: The moving part mainly consists of a magazine and a push cylinder. Has been placed in the longitudinal bin in the workpiece detection sensor detection in place, driven by a single rod cylinder pushes the plate forward, in time to ensure that the transverse trough in place in the workpiece, for the push material cylinder to launch the material good preparation.

Pneumatic manipulator device: 3 degrees of freedom pneumatic manipulator, cylinders and attached sensors. The whole handling mechanism can complete three degrees of freedom action, arm rotation, hand claw up and down, hand claw tightening.

Conveyor belt device: the conveyor belt is driven by three-phase asynchronous motor, in place detection at the end point of the conveyor belt, and material detection by inductive sensor and colour sensor. The conveyor belt adopts removable aluminium alloy bracket.

Material Sorting Device: The feeding pallet is driven by synchronous belt by stepping motor to convey the materials carried by the machine handling device to the corresponding chute, and pushed into the corresponding chute by the feeding cylinder.

Practical training projects

1. Installation and debugging project of pneumatic system:

Select the device configuration of the single out of the rod cylinder, single out of the double rod cylinder, rotary cylinder and other pneumatic actuating elements and single-control solenoid directional valves, double-control solenoid directional valves and magnetic switches and other pneumatic control elements, you can complete the following work tasks of pneumatic technology:

★ Installation of pneumatic direction control circuits;

★Installation of pneumatic speed control circuits;

★Installation of swing control circuits;

★Installation of pneumatic sequence control circuits;

★Installation of pneumatic manipulator devices;

★ Installation and commissioning of pneumatic systems;

2. Installation of electrical control circuits and PLC programme writing project:

Select the device configuration of PLC modules, inverter modules and command switches, sensors, etc., can complete the following PLC application technology work tasks:

★ Connection of motor forward and reverse control circuit and control programme writing;

★Connection and control programme writing for motor speed control circuit;

★Pneumatic direction control programme writing;

★Pneumatic sequential action control programme writing;

★Pneumatic manipulator control programme writing;

★Belt conveyor control programme writing;

★ Stepping motor control programme writing;

★Material sorting control programme writing;

★Material sorting equipment control programme writing;

★Automatic production line control programme writing.

3. electromechanical equipment installation and commissioning projects

Select the device configuration of electromechanical integration equipment components, PLC modules, inverter modules and command switches, sensors, etc., can complete the following electromechanical equipment installation and electromechanical integration technology work tasks:

★Adjustment of the coaxiality of the transmission device;

★Installation and adjustment of belt conveyors;

★Installation and adjustment of handling manipulator equipment;

★Installation and commissioning of object sorting equipment;

★Feeding equipment installation and commissioning;

★ Automatic production line equipment installation and commissioning.

4. automatic control system installation and commissioning projects

Select the device configuration of mechatronics equipment components, PLC modules, inverter modules and command switches, sensors, etc., can complete the following electromechanical equipment installation and mechatronics technology tasks:

★ Installation and debugging of a variety of sensors;

★Automatic control of manipulators;

★Automatic control of belt conveyors;

★Automatic control of mechatronics equipment;

★Installation and debugging of PLC control systems;

★Installation and debugging of automatic production lines.
