Equipment technical indicators 1、Dimensions：L×W×H=490×300×130mm 2、Capacity：≤0.5KVA 3、Ambient Temperature: -5℃~40 4、Safety protection measures: short-circuit protection, power supply isolation circuit, safety in line with relevant international standards.
Equipment Overview
The experiment box adopts the sky blue case, the internal use of a thickness of 2mm circuit board, through the nine self-tapping screws fixed in the case, to ensure that the circuit board is reliably fixed in the case. The circuit board is powered by the current popular switching power supply with strong load carrying capacity, and with strong electric isolation and protection circuit. All the observable and debuggable components are distributed on the front side of the circuit board, and the others are distributed on the back side, which is conducive to the neatness of the panel and convenient for students' experiments.
Equipment training program
1. Diode switching characteristics and applications
2. Crystal transistor switching characteristics and applications
3.TTL integrated logic and non-gate function and parameter test
4. Gate circuit logic function test and logic conversion
5. Analysis and design of combinational logic circuits
6. Flip-flops and their applications
7. Connection and driving experiments of integrated logic circuits
8. Timing circuit testing and research
9. Integrated counters and shift registers
10. Decoders and data selectors
11. Pulse generation circuits and monostable triggers
12.555 Time Base Circuits and Applications
13.Logic Function and Parameter Test of CMOS Integrated Logic Gate
14. TS gate, OC gate experiments
15.TTL different series of chip performance and parameter function test
16.TTL and non-gate driving ability test
17.Logic pen experiment and analysis
18.Translation driver CD4511 logic function test
19.MSI Adder
20.Competition Adventure
21.Shift Registers and their Applications
22. Counters and their applications
23. Analysis and Application of Timing Logic Circuits
24. Pulse Splitters and their Applications
25. Schmitt Flip-Flops and their Applications
26. Monostable Flip-Flop and its application experiments
27. Multiple analog switches and their applications
28.Digital Timer
29.Voltage Converter
30.Four-way Priority Judgment Circuit
31.Quadruple Frequency Division Circuit with Integrated JK Trigger
32. Optocoupler 4N25 Functional Tests
33.D/A, A/D Converter
